Foot
with vibration absorption
steel
- Components for assembling a swivel foot
- Application sectors: machine and equipment construction, logistics and assembly
- Damper plates absorb vibrations and prevent the swivel foot slipping
- Temperature range -30 °C to 70 °C
€19.49
plus sales tax
Added to your shopping cart
Designation
Foot
Version 1
with vibration absorption
Body material
steel
Component material
polyurethane
D=Plate diameter
74
Fmax=Load capacity max. kN
1,372
H1=Under pressure of 0/0.4/0.6
4 / 2,8 / 1,9
H=Height
21
D1
68
D2
9
Description
Material
Plate steel or stainless steel 1.4404.
Damper plate PUR elastomer (Sylomer V12).
Damper plate PUR elastomer (Sylomer V12).
Version
Plate trivalent blue passivated or bright.
Damper plate grey, glued in, anti-slip.
Temp. range -30 °C to +70 °C.
Damper plate grey, glued in, anti-slip.
Temp. range -30 °C to +70 °C.
Drawing reference
1) damper plate
Note
The load rating given in the table is a recommendation of the permanent static load up to which the damper plate should be used.
This static load corresponds to a surface pressure of 0.4 N/mm², at which the material reaches its optimum absorption properties. Here it is taken into account that under dynamic loading an additional load of up to 0.6 N/mm² may occur.
The damper plate absorbs vibrations and prevents the machine foot slipping.
